1. The PCB adopts high-end 4-layer 1oZ thickened copper sheet and adopts high-end resin plug hole PCB production process, with strong anti-interference ability。

2. Adopting industrial grade LDO, resistant to high temperature。

3. Use inline connectors for easy installation and soldering free。

4. The board comes with 4 programmable illusion LED lights, which can freely switch LED lighting effects。

5. Reserve an external LED light strip with a 12V power supply, and customize the remote control channel for light strip switch control。

6. The image transmission power supply can be freely turned on or off by setting a switch channel at the ground station, facilitating ground reference adjustment。

7. Adopting high-quality Murata capacitors from Japan, with strong filtering performance。

8. Eight motor control signal outputs。

9. Equipped with 6P sky terminal seat。

10. RX2 to SBUS。
